Quick Details

  • Brand Name: TengShun
  • Model Number: TS-2024C
  • Use: Lead-Acid Battery pack
  • Type: Electric
  • Place of Origin: Guangdong, China (Mainland)
  • Name: lead acid battery charger 36v
  • Input voltage: 100-240VAC 50/60Hz
  • Input plug: EU US UK AUS Plugs
  • Output: 12v4a 24v2a 36v1.5a 48v1a
  • Output Connector: XLR Alligato Clips DC Jack
  • Certificate: CE UL PSE KC GS ROHS
  • Charge mode: CC---CV---Float charge

Packaging & Delivery

Packaging Details: set package in white box

lead acid battery charger 36v1.5a 12v4a 24v2a 48v1a


Lead Acid battery charger

Our company was established in 1999 with about 250 employees,ShenZhen ,China.TengShun is a young and rapidly growing company within LifePo4 battery pack,Lithiumion battery pack,LifePo4 battery charger,Lithiumion battery charger,smart Ni-mh battery charger, Lead acid battery charger and power adaptor, which has got CE,FCC,ROHS,SAA,UL,EK,PSE certificate approval for the world application.We operate from our production factility in the national manufacturing standard and custom made products for original equipment manufacturers and customer markets.

Our factory workshop

A.product descriptions


ModelLead acid battery charger
Input100-240Vac 50/60Hz
Input plug(power cords)EU US UK AUS Korea Japan South Africa plugs(power cable)
Battery voltage6V/12V/24V/36V/48V/60V
Output12v4a  24v2a  36v1.5a  48v1a
Output Voltage at no load

6.8-6.9V at no load: 6V battery

13.6-13.8V at no load: 12V battery

20.4-20.7V at no load: 18V battery

27.6-27.8V at no load: 24V battery

41.4-42V at no load: 36V battery

54.4-55.2V at no load: 48V battery

Highest Charge Voltage

7.2-7.3V : 6V battery

14.4-14.8V : 12V battery

21.6-22.2V : 18V battery

29.2-29.6V : 24V battery

43.8-44.4V : 36V battery

58.4-59.2V : 48V battery

Charge mode3-stage Mode: CC---CV--float mode
Led Indicator(Dual Color)Red---in Charging; Green--Finish charge/ no load
Led Switch current10-15% of charge current
Safe ProtectionOver-load protection Over-current protection
Short circuit protection Polarity Reverse Protection
Safe CertificateCE  ROHS CB  GS  FCC  UL  SAA  PSE  KC
Output ConnectorDC jack, XLR, JST, Cigar Lighter, Alligator Clips,Viation Plug.etc
Power Consumption≤0.5W at Rated Voltage(adapter at no load)
Ripple And NoiseOutput voltage 1%, Ripple&Noise≤120mv
High-Voltage testPrimary to secondary: 3 kV / 5mA 60S
Leakage Current0.5mA(max) at input 240V AC
Drop Test0.75m drop test, 6 times
Burn-In Test100% load, 5hours
MTBF50,000 hours@ 25°C
ApplicationUPS, E-bike, Motor, Solar systems, Torch, Lamps.etc.
Warranty2 years
Lead time10 days
Contact InfoSkype ID: charger7772   Email: sunjoy5@163 dot com
Packing  Way100pcs/Ctn(Wall Mount Type)     50pcs/Ctn(desktop type)
Ctn size: 44*39*29cm   white box/unit
Charge Drawing

B.Packing details :

1.Set product in white box

2. Customized package available

C.Business condition

1.terms:FOB shenzhen

2.payment:T/T or L/C are accepted


main products


 6V500mA  6V800mA  6V1.2A  7.2V1.2A  12V800mA
 6V1.5A  12V1A  24V0.5A
6V2A  7.2V2A  12V1.5A
12V2A  18V1A  24V1A
12V1A  6V1.2A  24V0.5A Interchangeable
 12V2.5A  18V2A  24V1.5A
12V4A  24V2A  36V1.5A  48V1A
12V5A  24V3A  36V2A  48V1.5A
12V8A  24V5A  36V4A  48V3A
12V20A  24V10A  36V8A  48V5A
